Baomain DC 6-36V 300mA NO 3-wire Capacitance Proximity PNP Switch Sensor Detector 1-25mm

It is a component widely used in automatic control industry for detecting, controlling, and noncontact switching. When proximity switch is close to some target object, it will send out control signal. Dectecting metal object. It’s widely used in machine, paper making, light industry for limiting station, orientation taking count, speeding trial ect.

Features

• Product Name : Capacitive Proximity Switch;Model : LJC30A3-H-Z/BY;Wire Type : DC 3 Wire (Brown, Black, Blue);Switch Appearance Type : Cylinder Type
• Theory : Capacitance Sensor;Output Type : PNP NO(Normal Open);Diameter of Head : 30mm;Detecting Distance : 1-25mm
• Detecting Object : Metal or Nonmetal Material;Supply Voltage : DC 6-36V;Current Output : 300mA;Response Frequency : 100Hz
• Operating Temperature : -25°C to +65°C (Non-freezing Condition);Size : 7.5 x 4cm/3” x 1.6” (L*Max. Dia);Cable Length : 1.2m/47
• Net Weight : 130g;Color : Silver Tone, Yellow, Gray;Package Content : 1 x Capacitive Proximity Switch
